Intel Core I5 12400
Sale price  $522.00 Regular price  $1,000.00
power
number of cores
model number

SPECIFICATIONS

64-bit support: Yes



Bus speed: 8 GT/s DMI

Family: Intel Core 5

Market segment: Desktop

Memory Types: DDR4-2666

Model number: i5-12400

PCI Express Revision: 3

Physical memory: 128 GB

Thermal Design Power: 65 Watt

Total Cores: 16

Total Threads: 24

application: Desktop

brand name: INTEL

chip process: 14 nanometers

cpu frequency: 3.2 GHz

place of origin: Guangdong, China

private mold: No

processor brand: Intel

processor type: Intel Core I5

products status: New,OPEN-BOX

socket type: FCLGA1200

type: 6-core

virtualization technology support: Yes



Product Description

Product Description.jpg



New Intel Core i5 12400 Processor 6 Cores up to 4.4 GHz 65W DDR4 Memory CPU Support Socket FCLGA1200 Motherboard Z590 Z690



Intel Core i5-12400 is a desktop processor with 6 cores, launched in January 2022. It is part of the Core i5 lineup, using the Alder Lake-S architecture with Socket 1700. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 12 threads. Core i5-12400 has 18MB of L3 cache and operates at 2.5 GHz by default, but can boost up to 4.4 GHz, depending on the workload. Intel is building the Core i5-12400 on a 10 nm production process, the transistor count is unknown. The multiplier is locked on Core i5-12400, which limits its overclocking capabilities.
With a TDP of 65 W, the Core i5-12400 consumes typical power levels for a modern PC. Intel's processor supports DDR4 and DDR5 memory with adual-channel interface. For communication with other components in the machine, Core i5-12400 uses a PCI-Express Gen 5 connection. This processor features the UHD Graphics 730 integrated graphics solution.
Hardware virtualization is available on the Core i5-12400, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.



Intel® Core™ i5-12400 Processor  (18M Cache- up to 4.40 GHz)
Essentials
Product Collection 12th Generation Intel® Core™ i5 Processors
Code Name Products formerly Alder Lake
Vertical Segment Desktop
Processor Number i5-12400
Status Launched
Launch Date Q1'22
Lithography Intel 7
Use Conditions PC/Client/Tablet

CPU Specifications
Total Cores 6
# of Performance-cores 6
# of Efficient-cores 0
Total Threads 12
Max Turbo Frequency 4.40 GHz
Performance-core Max Turbo Frequency 4.40 GHz
Performance-core Base Frequency 2.50 GHz
Cache 18 MB Intel® Smart Cache
Total L2 Cache 7.5 MB
Processor Base Power 65 W
Maximum Turbo Power 117 W

Supplemental Information
Embedded Options Available Yes
Datasheet View now

Memory Specifications
Max Memory Size (dependent on memory type) 128 GB
Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels 2
Max Memory Bandwidth 76.8 GB/s

Processor Graphics
Processor Graphics   Intel® UHD Graphics 730
Graphics Base Frequency 300 MHz
Graphics Max Dynamic Frequency 1.45 GHz
Graphics Output eDP 1.4b |  DP 1.4a |  HDMI 2.1
Execution Units 24
Max Resolution (HDMI)  4096 x 2160 @ 60Hz
Max Resolution (DP)  7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)  5120 x 3200 @ 120Hz
DirectX* Support 12
OpenGL* Support 4.5
Multi-Format Codec Engines 1
Intel® Quick Sync Video Yes
Intel® Clear Video HD Technology Yes
# of Displays Supported   4
Device ID 0x4692 / 0x4682
OpenCL* Support 2.1

Expansion Options
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations   Up to 1x16+4 |  2x8+4
Max # of PCI Express Lanes 20

Package Specifications
Sockets Supported FCLGA1700
Max CPU Configuration 1
Thermal Solution Specification PCG 2020C
TJUNCTION 100°C
Package Size 45.0 mm x 37.5 mm

Advanced Technologies
Intel® Gaussian & Neural Accelerator 3
Intel® Thread Director No
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Optane™ Memory Supported   Yes
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0   No
Intel® Turbo Boost Technology   2
Intel® Hyper-Threading Technology   Yes
Intel® 64   Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Volume Management Device (VMD) Yes

Security & Reliability
Intel® Threat Detection Technology (TDT) Yes
Intel® Standard Manageability (ISM)   Yes
Intel® AES New Instructions Yes
Secure Key Yes
Intel® OS Guard Yes
Execute Disable Bit   Yes
Intel® Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel® Control-Flow Enforcement Technology Yes
Intel® Virtualization Technology (VT-x)   Yes
Intel® Virtualization Technology for Directed I/O (VT-d)   Yes
Intel® VT-x with Extended Page Tables (EPT)   Yes

I5 12400 01.jpgI5 12400 02.jpgI5 12400 03.jpgI5 12400 04.jpgI5 12400 05.jpgI5 12400 06.jpgI5 12400 07.jpgI5 12400 08.jpgI5 12400 09.jpgI5 12400 10.jpgI5 12400 11.jpg
